One of my primary goals with CapstoneED v2 was to have the repo be self-contained and easy to spin up. In this post I will document the process I went through to dockerize everything, as well as the decisions I made along the way.

Intro

First let me set the scene of what we are working with. There is 1 mono-repo that includes everything, and part of that mono-repo is a git submodule to the API repo. This way, I can still only “clone one repo” and get going, while not losing any of the history in the API repo. These are the files we will be working with today:

capstoneed/
├── apps/
│   └── api/
│       └── Dockerfile
├── docker-compose.base.yml
└── docker-compose.yml

The root docker-compose.yml and docker-compose.base.yml are used to orchestrate everything in the mono-repo. The root Dockerfile is used to build and “deploy” the Angular apps. apps/api/Dockerfile is used to build and deploy the API itself.

The way I have structured things is that docker-compose.base.yml includes all of the common services, configuration, etc, while docker-compose.yml extends those services and groups them in profiles. For example, let’s say we have the following in base:

# in docker-compose.base.yml
services:
  database:
    image: postgres:17
  ports:
    - "5432:5432"
    # ... omitted for brevity

Then in our compose file we can setup the following:

# in docker-compose.yml
services:
  database-dev:
    extends:
    file: docker-compose.base.yml
    service: database # This name must match the service in above file
  profiles: ["backend-dev"]
  ports:
    - "5480:5432" # 5432 is for the production database, we use 5480 in dev

What this affords is to share common config while overriding whatever we need per profile. Now by running docker compose --profile backend-dev up, Docker will bring up everything that has backend-dev in their profiles list AND everything that has no profile attached. That last part is really important, as it can be used to have services that always run, but it can also cause unintended conflicts with ports, etc.

Dockerfile

I am going to start with the Rails API first. A lot of the build is based on the Docker docs for Rails, but I have also heavily modified it for proper local development. So let’s start with our Dockerfile layout:

ARG RUBY_VERSION=3.4.7
ARG RAILS_UID=1000
ARG RAILS_GID=1000

####################################
# Base
####################################
FROM ruby:${RUBY_VERSION}-slim AS base
# Do things that are needed in both prod and dev
# i.e. apt-get install dependencies, postgres client, etc.

ARG RAILS_GID
ARG RAILS_UID

RUN groupadd --system --gid ${RAILS_GID} rails
RUN useradd rails --uid ${RAILS_UID} --gid ${RAILS_GID} --create-home --shell /bin/bash

####################################
# Development
####################################
FROM base AS development

# bundle install, set environment to development, etc

ARG RAILS_GID
ARG RAILS_UID
USER ${RAILS_UID}:${RAILS_GID}

ENTRYPOINT ["/opt/app/bin/dev-entrypoint.sh"]
EXPOSE 3000
CMD ["rails", "server", "-b",  "0.0.0.0"]

####################################
# Production Build
####################################
FROM base AS production-build
# Most of the stuff in here is from
# https://docs.docker.com/guides/ruby/containerize/
# like running precompile and setting any additional
# environment stuff needed

####################################
# Production
####################################
FROM base AS production

COPY --from=production-build "${BUNDLE_PATH}" "${BUNDLE_PATH}"
COPY --from=production-build /opt/app /opt/app

RUN chown -R rails:rails db log storage tmp

ARG RAILS_GID
ARG RAILS_UID
USER ${RAILS_UID}:${RAILS_GID}

ENTRYPOINT ["/opt/app/bin/docker-entrypoint.sh"]
EXPOSE 3000
CMD ["./bin/rails", "server"]

That is a lot of Dockerfile even though I tried to abbreviate it as much as possible. My goal with this file was to break it into cacheable stages to reduce churn and wait times when running docker build.

There are a couple of things that I would like to point out here. First is the fact that we are creating a rails:rails user:group and running Rails through it. The reason is two-fold:

1. Security: If for whatever reason the Rails process is compromised, you are not running as root.
2. Ease of use in dev: If you run the application as root in dev and you are mounting the local source code into the container, you will end up creating files owned by the root user. For instance, app/log/development.log or the various files in app/tmp, like the server.pid. Which can result in permission errors down the line.

The other thing that I would like to point out is that both dev and prod have an entrypoint.sh file. For production I am using the one from the docs. For development however, I am using the following script:

#!/bin/bash -e

PID_FILE="tmp/pids/server.pid"
if [[ -f "$PID_FILE" ]]; then
    rm -f "$PID_FILE"
fi

if [[ -v WITH_DEBUGGER ]]; then
    bundle exec rdbg --open=vscode --host 0.0.0.0 --port 1234 -- "${@}"
else
    exec "${@}"
fi

This script makes sure the PID file is cleared at startup, which in theory could be an issue if you are not careful. The reason I needed this functionality is because sometimes when terminating the container it might not be a graceful shutdown, which leaves the PID behind. The other benefit is that it allows me to define WITH_DEBUGGER in the compose file and it will automatically wait for me to attach from VS Code. This last part could be more configurable, but it works good enough for now.

Putting it together in compose

Now in my compose file I can have the following, which allows me to have both the database and the API under one profile and bring them up at once. The actual compose file has more stuff to handle environment files, etc, but you get the gist.

postgres-dev:
  extends:
    file: docker-compose.base.yml
    service: database-base
  profiles: ["backend-dev"]
  environment:
    # Environment variables
  ports:
    - "5432:5432"

api-dev:
  extends:
    file: docker-compose.base.yml
    service: api-base
  build:
    target: development
  profiles: ["backend-dev"]
  environment:
    # Other environment variables
    - WITH_DEBUGGER=1
  ports:
    - 1234:1234 # for the debugger
  volumes:
    - "./apps/api:/opt/app"
  depends_on:
    - postgres-dev
